24V 8Ah Sealed Lead Acid Battery – GS8D-24 Compatible Replacement (Model GS24-8)
Model Overview
Model: GS24-8
Nominal Voltage: 24 V
Capacity: 8 Ah (C10 = 7.4 Ah)
Weight: ~4.7 kg (10.34 lbs)
Terminal Type: F1 & F2 (standard faston spade connectors)
Case Material: ABS (flame-retardant)
Dimensions:
- Length = 188 mm (7.40 in)
- Width = 102 mm (4.02 in)
- Height = 95–100 mm (3.74–3.94 in)
GS24-8 24V 8AH Rechargeable Battery (Small Size)
The GS24-8 is a compact and highly reliable 24V, 8AH battery, designed for various applications where consistent power is essential. With a durable construction and advanced technology, this battery is ideal for use in telecommunications, UPS systems, energy storage, medical and electronic equipment, and control systems.
This battery is a high-quality solution for any application requiring compact and long-lasting energy storage, with exceptional discharge and charging capabilities, ensuring your system remains powered when you need it the most.
Applications:
- Telecommunications: Reliable power for communication systems.
- UPS Systems & Data Centers: Ensures power stability for critical infrastructure.
- Energy Storage & Electric Systems: Supports sustainable energy solutions.
- Medical & Electronic Equipment: Powers sensitive equipment with consistent reliability.
- Control Equipment: Ideal for industrial applications requiring uninterrupted power.
Safety & Compliance:
- UL Certified, TLC Certified, CE Certified
- Manufactured in Jiage® certified production facilities (ISO 9001, ISO 14001, and ISO 45001).
- Specialized Exhaust Structure: Provides added safety and flexibility for easy installation and maintenance.
Long Life and Reliability:
- Float Life: Up to 5 years under normal conditions (at temperatures below 25°C).
- Temperature Effects: The battery’s performance remains stable, with minimal degradation across various temperatures, ensuring a long lifespan.
Benefits:
- Reliable and durable performance in a compact form factor.
- Safe and easy installation with advanced sealing technology.
- Ideal for use in various energy and backup power applications.
Constant Current Discharge @ 25°C (A)
| F.V/Time | 5min | 10min | 15min | 30min | 1h | 2h | 3h | 4h | 5h | 6h | 10h | 20h |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1.85V/cell | 21.74 | 16.04 | 12.03 | 7.46 | 4.40 | 2.57 | 1.95 | 3.88 | 1.21 | 1.10 | 0.72 | 0.38 |
| 1.80V/cell | 22.49 | 16.59 | 12.77 | 7.71 | 4.55 | 2.66 | 2.02 | 3.59 | 1.32 | 1.14 | 0.76 | 0.42 |
| 1.75V/cell | 22.91 | 16.90 | 12.94 | 7.86 | 4.71 | 2.71 | 2.06 | 3.49 | 1.39 | 1.21 | 0.80 | 0.47 |
| 1.70V/cell | 23.31 | 17.19 | 12.98 | 8.08 | 4.76 | 2.72 | 2.12 | 3.50 | 1.42 | 1.22 | 0.82 | 0.50 |
| 1.67V/cell | 23.61 | 17.38 | 13.08 | 8.33 | 4.87 | 2.78 | 2.12 | 3.51 | 1.49 | 1.26 | 0.85 | 0.52 |
| 1.60V/cell | 23.81 | 17.57 | 13.17 | 8.17 | 4.82 | 2.81 | 2.14 | 4.25 | 1.33 | 1.19 | 0.79 | 0.42 |
Constant Current Discharge @ 25°C (W)
| F.V/Time | 5min | 10min | 15min | 30min | 1h | 2h | 3h | 4h | 5h | 6h | 10h | 20h |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1.85V/cell | 42.40 | 31.27 | 23.45 | 14.55 | 8.57 | 5.01 | 3.81 | 7.57 | 2.37 | 2.15 | 1.40 | 0.74 |
| 1.80V/cell | 43.85 | 32.34 | 24.25 | 15.10 | 8.93 | 5.32 | 4.32 | 7.65 | 2.45 | 2.22 | 1.50 | 0.78 |
| 1.75V/cell | 44.67 | 32.95 | 24.71 | 15.32 | 9.04 | 5.38 | 4.16 | 7.79 | 2.52 | 2.27 | 1.48 | 0.80 |
| 1.70V/cell | 45.45 | 33.35 | 24.75 | 15.44 | 9.09 | 5.42 | 4.18 | 7.76 | 2.55 | 2.30 | 1.52 | 0.81 |
| 1.67V/cell | 46.03 | 33.55 | 24.91 | 15.63 | 9.23 | 5.50 | 4.27 | 7.84 | 2.58 | 2.32 | 1.54 | 0.82 |
| 1.60V/cell | 46.44 | 34.25 | 25.68 | 15.93 | 9.39 | 5.49 | 4.18 | 8.30 | 2.59 | 2.36 | 1.54 | 0.81 |
What are the main applications of the GS24-8 24V 8AH battery?
The GS24-8 24V 8AH battery is ideal for a variety of applications, including telecommunications, UPS systems, data centers, energy storage, and medical equipment. It provides reliable power for critical systems, ensuring uninterrupted performance for businesses and personal use.
What are the main applications of the GS24-8 24V 8AH battery?
The GS24-8 24V 8AH battery offers a floating life of up to 5 years under optimal conditions (at temperatures below 25°C). This long-lasting battery is designed to provide stable and reliable power over an extended period, making it a perfect choice for both commercial and residential energy storage needs.
What is the temperature range for the GS24-8 battery's operation?
The GS24-8 24V 8AH battery operates efficiently in a wide temperature range from -20°C to 55°C (-4°F to 131°F). Whether used in hot or cold environments, this battery ensures reliable performance, making it suitable for a wide range of applications and locations.
Is the GS24-8 battery safe and certified?
Yes, the GS24-8 24V 8AH battery is UL Certified, CE Certified, and TLC Certified. It is manufactured in Jiage® ISO-certified production facilities (ISO 9001, ISO 14001, ISO 45001), ensuring high standards for safety, quality, and environmental responsibility. With its advanced exhaust structure and sealing technology, the battery is designed to be both safe and reliable for various industrial and commercial uses.
