Cylindrical Rechargeable Lithium Ion Battery Cell
Operating Voltage Range: 3.0V ~ 4.2V
Nominal Voltage: 3.7V
Nominal Capacity: 2500mAh
Minimum Capacity: 2300mAh
Rated Energy: 9.25Wh
- FREE FAST SHIPPING
- 2 YEAR WARRANTY
Cylindrical Rechargeable Lithium Ion Battery Cell – 3.7V (2500mAh)
The 3.7V 2500mAh Lithium-Ion Rechargeable Battery Pack is engineered to provide 9.25Wh of energy, offering reliable and efficient power for a variety of applications. With a maximum continuous discharge current of 3A and up to 1000 charge cycles at 80% DoD, this battery is designed to meet the demands of both personal and commercial energy needs. Ideal for use in electric vehicles (EVs), e-bikes, solar storage systems, and backup power, it delivers sustainable and long-lasting performance.
Utilizing advanced lithium-ion technology, this battery ensures excellent safety and thermal stability, reducing the risk of overheating while maintaining high efficiency. It is equipped with an IP65 rating for dustproof and waterproof protection, making it suitable for harsh environments, whether used indoors or outdoors.
Applications
- Solar energy storage for both residential and commercial systems.
- Electric vehicles (EVs) and e-bikes for high-capacity energy needs.
- Backup power for residential and small commercial properties.
- Suitable for use in marine environments for powering onboard systems.
- Off-grid power systems for reliable energy in remote areas.
Technical Specifications
- Operating Voltage Range: 3.0V ~ 4.2V
- Nominal Voltage: 3.7V
- Nominal Capacity: 2500mAh
- Minimum Capacity: 2300mAh
- Rated Energy: 9.25Wh
- Max Continuous Discharge Power: 9W
- Fast Charging Voltage: 4.2V
- Standby Charging Voltage: 4.0V ~ 4.1V
- Floating Charging Voltage: 4.0V ~ 4.1V
- Discharge Low Protection Voltage: 3.0V
- Standard Charging Current: 1A
- Recommended Charging Current: 2A
- Max Charging Current: 3A
- Standard Discharge Current: 1A
- Max Continuous Discharge Current: 3A
- Internal Resistance: ≤100mΩ
- Charging Temperature: 0°C ~ 45°C
- Discharge Temperature: -20°C ~ 60°C
- Cycle Life (25°C, 80% DoD): 500-1000 cycles
- Cells Configuration: Single-cell
- Dustproof / Waterproof Level: IP65
- Weight: ≈40g
- Dimensions (LWH): 18.6 x 65 mm
Benefits
- High capacity of 2500mAh ensures sufficient power for various electronic devices and systems.
- Fast charging capabilities ensure quick energy replenishment.
- IP65 rating ensures dustproof and waterproof protection, making it suitable for harsh environments.
- Long-lasting, with up to 1000 charge cycles at 80% DoD.
- Built-in protection circuits ensure safe operation by preventing overcharging, over-discharging, and short circuits.
Long Life and Reliability
- 1000 cycle life at 80% DoD ensures this battery will last for many years with minimal degradation.
- Low internal resistance (≤100mΩ) increases energy efficiency, reducing heat and improving system performance.
- Built-in safety features prevent damage, ensuring long-term safety and dependability.
- Works efficiently with continuous discharge rates up to 3A, making it suitable for demanding applications.
What is the capacity of the Cylindrical Rechargeable Lithium-Ion Battery Cell?
The capacity of this battery cell is 2500mAh, providing reliable power for a variety of applications.
What is the capacity of the Cylindrical Rechargeable Lithium-Ion Battery Cell?
The maximum continuous discharge current of this battery is 3A, making it suitable for moderate power needs.
Can this battery be used for electric vehicles (EVs)?
Yes, this battery is well-suited for electric vehicles (EVs) and e-bikes due to its high energy density and reliable discharge capabilities.
What is the charging time for this battery?
Charging time for this battery typically ranges from 2 to 4 hours, depending on the charger used and the current provided.
