Drone Battery Pack
- Operating Voltage Range: 3.0V ~ 4.2V
- Nominal Voltage: 3.7V
- Nominal Capacity: 2500mAh
- Minimum Capacity: 2300mAh
- Rated Energy: 9.25Wh
- FREE FAST SHIPPING
- 2 YEAR WARRANTY
The Drone Battery Pack is engineered to provide 148Wh of high-density energy, ensuring extended flight times and stable power delivery for professional aerial platforms. Featuring a 25C continuous discharge rate and a lightweight, compact form factor, this battery is built to meet the rigorous demands of high-performance propulsion systems. Whether you are operating enterprise inspection drones, agricultural sprayers, or heavy-lift cinematography rigs, this pack provides the instantaneous current needed for agile maneuvers and sustained hovering.
Developed with advanced Lithium Polymer (LiPo) chemistry, this battery offers an exceptional power-to-weight ratio, maximizing payload capacity without sacrificing endurance. Each pack is constructed with high-quality cells that maintain low internal resistance, ensuring consistent voltage output even during high-throttle transitions. Designed for durability and reliability in the field, it features reinforced balancing leads and a high-current XT90 connector, making it a dependable energy source for mission-critical flight operations.
Applications
- Aerial Photography & Videography: Perfect for providing long-lasting power to drones used for capturing high-quality images and videos.
- Commercial & Industrial Drones: Ideal for drones used in agriculture, surveillance, and inspection, offering reliable and sustained power for extended flights.
- Search & Rescue Operations: Provides the necessary energy for drones in search and rescue missions, ensuring operational readiness in critical situations.
- Military Drones: Suitable for military-grade drones requiring high-capacity and long-duration energy for reconnaissance and defense operations.
- Recreational Drones: Powers hobbyist drones for recreational flying, providing consistent performance for extended flight times.
Technical Specifications
- Operating Voltage Range: 3.0V ~ 4.2V
- Nominal Voltage: 3.7V
- Nominal Capacity: 2500mAh
- Minimum Capacity: 2300mAh
- Rated Energy: 9.25Wh
- Max Continuous Discharge Power: 9W
- Fast Charging Voltage: 4.2V
- Standby Charging Voltage: 4.0V ~ 4.1V
- Floating Charging Voltage: 4.0V ~ 4.1V
- Discharge Low Protection Voltage: 3.0V
- Standard Charging Current: 1A
- Recommended Charging Current: 2A
- Max Charging Current: 3A
- Standard Discharge Current: 1A
- Max Continuous Discharge Current: 3A
- Internal Resistance: ≤100mΩ
- Charging Temperature: 0°C ~ 45°C
- Discharge Temperature: -20°C ~ 60°C
- Cycle Life (25°C, 80% DoD): 500-1000 cycles
- Cells Configuration: Single-cell
- Dustproof / Waterproof Level: IP65
- Weight: ≈40g
- Dimensions (LWH): 18.6 x 65 mm
Benefits
- High Capacity: With a 2500mAh capacity, this battery ensures ample power for drones, extending flight times for various applications.
- Fast Charging: Supports quick recharging with a fast charging voltage of 4.2V, minimizing downtime between flights.
- IP65 Rating: The dustproof and waterproof design makes this battery pack suitable for drones operating in diverse and challenging environments.
- Long-lasting: Offers up to 1000 charge cycles with 80% Depth of Discharge (DoD), ensuring extended longevity for consistent performance.
- Built-in Protection Circuits: Includes safety features to prevent overcharging, over-discharging, and short circuits, enhancing the safety of your drone operations.
Long Life and Reliability
- Cycle Life: Capable of lasting up to 1000 cycles at 80% DoD, ensuring dependable service for multiple years with minimal performance degradation.
- Low Internal Resistance: Reduces heat and improves energy efficiency, enhancing the overall performance of the drone system.
- Safety Features: Built-in protection against damage, ensuring safe operation and reliable long-term use in all conditions.
- High Continuous Discharge: Delivers continuous discharge rates up to 3A, ensuring consistent and reliable performance even under demanding conditions.
How long will a drone battery last?
A drone battery typically lasts between 20-30 minutes of flight time, depending on the drone model and battery capacity.
How long will a drone battery last?
Drone batteries are designed specifically for drones, and their voltage and capacity may not be suitable for other devices. Always check compatibility.
How long does it take to charge a drone battery?
Charging time for a drone battery is usually around 1-2 hours, depending on the charger used and the battery’s capacity.
Are drone batteries safe to use in cold weather?
Drone batteries can be affected by cold temperatures, leading to reduced flight time. It’s recommended to store and use them in temperatures above 0°C for optimal performance.
